How do I access Umbraco forms uploaded files from code?

Questions
,
1

We’re building a function where partners (to our client) can submit an Umbraco form and an editor will then look at the form submission values and either accept or deny it (via a custom page that we’ve built). If the editor accept it, a new page will be created.

Our problem is that the uploaded image (from UB Form fileupload-element) doesn’t seem to be reachable in the code. We want to move that image from /media/forms/upload/ to a folder of our choosing plus set an image value on the new page that’s being created.

The uploaded image has a url that looks like this: “/media/forms/upload/form_e4ce59d4-e91f-41e8-b0ae-18b2820c1d02/595e3d4f-67f3-4360-b60e-2aecb8aec1ba/test-image.jpg” and if I try to access it via mediaService.GetMediaByPath(); it returns null. I’ve also tried mediaService.GetById and pass the guid (595e3d4f-67f3-4360-b60e-2aecb8aec1ba in my example) and it returns null as well.

There has to be some way of accessing these images like with any other Umbraco image, right?

2

mediaService.GetMediaByPath() will return null as this isn’t a media item (eg listed in the media area of the backoffice). It’s just been stored on disk by Umbraco Forms, similar to the File Upload property .

So you’ll have to do the heavy lifting…

Also as it’s not always the case that it’s a local filessytem, could be blob storage etc.. I’d recommend using the MediaFileManager service.

@using Microsoft.AspNetCore.Hosting;
@using Umbraco.Cms.Core.IO
@inject MediaFileManager _mediaFileManager
@inject IWebHostEnvironment _webHostEnvironment

    var url = "/media/forms/upload/form_e4ce59d4-e91f-41e8-b0ae-18b2820c1d02/595e3d4f-67f3-4360-b60e-2aecb8aec1ba/test-image.jpg";
    string webRootPath = _webHostEnvironment.WebRootPath;
    var path = System.IO.Path.Combine(webRootPath, System.IO.Path.Combine(url.Split('/', StringSplitOptions.RemoveEmptyEntries)));

    if (_mediaFileManager.FileSystem.FileExists(path))
    {
        _mediaFileManager.FileSystem.AddFile("{newpath...}", path, overrideIfExists: true, copy: true);
       // copy: false if you aren't bothered about broken links in the uForms backoffice/emails you've sent
        // create your node and assign the new path to your property.
      // might want to use FileUpload or MediaPicker property??
         ....
    }
3

Hi Mike

Awesome, thank you! Locally we have the media-folder on an external disk and test/production is on Umbraco cloud. Does it work with MediaFileManager then also (I haven’t had the time to test your snippet yet)?

4

Yep MediaFileManager for exactly that.. Umbraco Cloud media filestore is Azure Blob Storage.

5

Thank you! I’ll test it out and get back to you :slight_smile:

6

I’ve just tried it out and it works like a charm. Thank you Mike!

For anyone wondering, here’s a simple snippet on how to create an Image file under the media root:

@inject MediaFileManager _mediaFileManager
@inject IMediaService _mediaService;
@inject IContentTypeBaseServiceProvider contentTypeBaseServiceProvider
@inject MediaUrlGeneratorCollection _mediaUrlGeneratorCollection
@inject IShortStringHelper _shortStringHelper

var url = “/media/forms/upload/form_e4ce59d4-e91f-41e8-b0ae-18b2820c1d02/595e3d4f-67f3-4360-b60e-2aecb8aec1ba/test-image.jpg”;

if (_mediaFileManager.FileSystem.FileExists(url))
{
    var fileName = url.Split('/').LastOrDefault();
    var stream = _mediaFileManager.FileSystem.OpenFile(url);

    var media = _mediaService.CreateMedia(fileName, Constants.System.Root, Constants.Conventions.MediaTypes.Image);
    media.SetValue(_mediaFileManager, _mediaUrlGeneratorCollection, _shortStringHelper, contentTypeBaseServiceProvider, Constants.Conventions.Media.File, fileName, stream);

    var result = _mediaService.Save(media);
}
7

you might want to add using (stream) for disposal purposes..

Also I’ve never been a fan of allowing anything but folders in the media section root, since the versions where Umbraco had issues with large lists of images/assets in root causing slowdowns… probably addressed in more modern versions.. :slight_smile:

docs have a sample..

8

In the finished code I’ll move the files to a folder that we chose in our sites settings page , I just wanted to show a little snippet in case someone else googled this problem. I took the code from docs actually :slight_smile:
