BlockList inside BlockGrid, how?

Questions
1

V13.7.1 + BlockPreview package

Trying my best to use a blockgrid block to add a carousel. Each item in the carousel has it’s own link, text, layout controls as well as the image, so I thought I’d have each one as a blocklist item and have a blockgrid (HeroBannerBlock) with just the blocklist (HeroBannerItem) as it’s only content. So far, so good.

Now I’m totally confused as to exactly what I need to render this in the back office.

If I add a HeroBannerBlock, then I can see an “Add Hero Banner Item” in the slideout. If I click on that, it fails, no further slideout, nothing.

As for partials, I now just have a HeroBannerItem.cshtml which would be the full carousel code. However, it breaks. If I replace it all with the work “Hello” then as soon as I click into “Add Hero Banner Item” I see the work “Hello” rendered in the slideout.

I suppose my questions are:-

  1. If I get it right, will this be beyond the scope of the BlockPreview package to render it in the back office?
  2. How do I get it right? Do I need a partial for HeroBannerBlock as well as one for the HeroBannerBlockItem?
  3. If I need a partial for HeroBannerBlock, what should be in it? I’ve tried one with just @Html.GetBlockListHtml(Model.Content.HeroBannerItem) in it, thinking it would then render out the BlockList, but it breaks.

What should be the right approach, whether I have to build my own backoffice renderer or not?

Thanks.

2

Ok, I’ve worked out why I didn’t get a slide out, it was because I had “Inline editing mode” active. Once I switched that off, I got a sensible slide out. Now the content shows on the web site, but it doesn’t show in the back office at all.

All I can see is an empty content border if I mouse over the area.

If I click into it to edit whatever’s there, all I see is a single “Add Hero Banner Item”, nothing else. Even though there must be one item there because it’s showing on the web page.

Any advice appreciated.

Thanks.

3

Finally got everything working (apart from the JS in the back office). So the answer was to have a Block Grid HeroBannerBlock partial which within it lists out the Block List HeroBannerBlockItems and contains all the logic and html for display on the web site. There is also a HeroBannerBlockItems partial which is ONLY for display in the back office. That’s handy because there are formatting changes needed to fit everything in neatly.

2 Likes
4

I see you have this resolved but if it helps I have examples of Block List in Block Grid here:

and

and a carousel here:
