Asset upload fails

(EDITED)

What I’m trying to do:

Upload a file (orginally 1.36 GB) to the assets in Umbraco. Currently having problems in:

  • dev-Env even with small files - see “integer Overflow error”
  • live-Env with large files - see “large files”

integer Overflow error (dev)

When trying to upload seemingly any file to the assets I get an error in the backoffice along the lines of:
The error shown below resulted from trying to upload a 17 kB webp file

Error: System.IO.InvalidDataException: Multipart body length limit -699400192 exceeded.

The interessting thing here is that I configured all configs to allow 2GB

appsettings.json

"Runtime": {
    "MaxQueryStringLength": 90,
    "MaxRequestLength": 2000000000
},

web.config

<requestFiltering>
    <requestLimits maxAllowedContentLength="2000000000" />
</requestFiltering>

Program.cs

builder.Services.Configure<FormOptions>(options =>
{
    options.MultipartBodyLengthLimit = 2000000000;
});

Large files fail to upload

When trying to upload a large file (1.36 GB) the upload stays at 100% and the debug conole of the brower shows the following. On the other hand files of a size like 300 or 825 MB have no problem in beeing uploaded.

Possibly unhandled rejection:

{
    "data": null,
    "status": -1,
    "config": {
        "method": "POST",
        "transformRequest": [
            null
        ],
        "transformResponse": [
            null
        ],
        "jsonpCallbackParam": "callback",
        "url": "/umbraco/backoffice/umbracoapi/media/PostAddFile",
        "fields": {
            "currentFolder": "1324",
            "contentTypeAlias": "umbracoAutoSelect",
            "propertyAlias": "umbracoFile"
        },
        "file": {
            "key": "8cd4722b-0127-4cae-a5a3-e5da31386fbe",
            "messages": []
        },
        "_isDigested": true,
        "_chunkSize": null,
        "headers": {
            "Accept": "application/json, text/plain, */*",
            "X-Requested-With": "XMLHttpRequest",
            "X-UMB-SEGMENT": null,
            "X-UMB-XSRF-TOKEN": "CfDJ8NmAoZtxGFBMmfT2L703U5tz5MfwPyG7y3DOdSdQGyQa-ZxkJ2UQLhhuSQoRHY154oG6cLiKc078eEeFr6LoLBzOXjsTy4RkHVMRT3HTR6bRFZ5zRPTMAPFKq7eK7o-Ajr5nRvD7iSES-YLNYswPvEza3VFno3OUI15M6Ev7cKUFvk1DuOGJlfqC2SPg7Dferg"
        },
        "_deferred": {
            "promise": {}
        }
    },
    "statusText": "",
    "xhrStatus": "error"
}

Furthermore, the post request get rejected with “NS_ERROR_CONNETION_REFUSED” after the upload “has finished” . I thought the problem might be the file size limitations but I adjusted both in the appsettings.json and the web.config just to be sure.

What am I running:

Dev:

  • JetBrains Rider with IIS-Express Run Config
  • Umbraco v13.7.0 (updated as recommend by LuukPeters

Live

  • Umbraco v13.6.0
  • inside a docker container
  • hidden behind a traefik proxy

I appriciate any help, thanks!

I know that in 13.7.0 there are some fixes for file uploads. It’s not specifically your situation, but maybe it’s related?
